HPVirtualServerDescription (ie HP-123456:010) breaks out the uniqueness number and port index from the WWPN. More...

Inheritance diagram for HPVirtualServerDescription:

Collaboration diagram for HPVirtualServerDescription:

Public Member Functions
	HPVirtualServerDescription (String wwn)
	create an instance with brief set to false. More...

	HPVirtualServerDescription (boolean brief, String wwn)
	create an instance with the given WWN. More...

String	descPort ()
	describe the WWPN's unique port label/index More...

String	toString ()
	return a description or alias for this WWN; if brief is set to true during the call to getDesc(), then a shorter description or alias will be returned More...

Public Member Functions inherited from WWNDesc.WWNDescInitiator
	WWNDescInitiator (String wwn)
	create an instance with brief set to false. More...

	WWNDescInitiator (boolean brief, String wwn)
	create an instance with the given WWN. More...

Public Member Functions inherited from WWNDesc
	WWNDesc (String wwn)
	create an instance with brief set to false. More...

	WWNDesc (boolean brief, String wwn)
	create an instance with the given WWN. More...

	WWNDesc (boolean brief, String wwn, DevRole role)
	create an instance with the given WWN. More...

String	descPort ()
	describe the WWPN's unique port label/index More...

String	toString ()
	describe the WWN: produce a short (shorter if this.brief = true) description suitable for use as an alias for this WWN More...

Static Public Member Functions
static WWNDesc	getDesc (boolean strong, boolean brief, String wwn)
	If this class matches or describes the given WWN, returns a new instance of this class loaded with the given WWN. More...

static WWNDesc	getDesc (boolean strong, boolean brief, String wwn, int role)
	If this class matches or describes the given WWN, returns a new instance of this class loaded with the given WWN. More...

Static Public Member Functions inherited from WWNDesc.WWNDescInitiator
static boolean	isA (int role)
	convenience function to use bit-masks to check for membership in this role More...

Additional Inherited Members
Protected Attributes inherited from WWNDesc
boolean	brief
	whether a more brief output should be offered in toString() (ie the difference between "VMax-HK192601234-12gB" and "VMax-1234-12gB") . More...

DevRole	role = DevRole.TARGET
	role of the device: Target, Switch, Initiator

BigInteger	wwn
	the WWN that the instance tried to describe

Detailed Description

HPVirtualServerDescription (ie HP-123456:010) breaks out the uniqueness number and port index from the WWPN.

This one is fairly weak in that HP clearly indicates the 00110a OUI is the unwashed-masses of roll-your-own-WWPN, and users do indeed roll random values. This class is intended more to provide guidance to the uniqueness of a 2nnn00110axxxxxx device wherein for consistent xxxxxx values, nnn does change.

http://h20628.www2.hp.com/km-ext/kmcsdirect/emr_na-c03169041-2.pdf http://h20000.www2.hp.com/bc/docs/support/SupportManual/c03314921/c03314921.pdf.

http://h20000.www2.hp.com/bc/docs/support/SupportManual/c02494590/c02494590.pdf. 50:01:43:80:02:A3:00:00 - 50:01:43:80:02:A4:FF:FF VCEM 50:06:0B:00:00:C2:62:00 - 50:06:0B:00:00:C3:61:FF HP Pre-defined (64 blocks of 1024 IDs: ie C2:62:00 - C2:65:FF

http://www.filibeto.org/unix/hp-ux/lib/os/vpar/6.0/vpars-6.0-npiv-4AA3-8665ENW.pdf The range that HP has reserved for NPIV is 0x50014c2000000000 to 0x50014c27ffffffff for Port WWNs and 0x50014c2800000000 to 0x50014c2fffffffff for Node WWNs. ... When manually configuring vHBAs, vWWNs may safely be picked from the range 0x100000110a0300 - 0x100000110a030fff

http://h20000.www2.hp.com/bc/docs/support/SupportManual/c03967142/c03967142.pdf 10:00:38:9d:30:60:00:00 - 10:00:38:9d:30:6f:ff:ff used in examples of API

50060b00 range used in http://www.filibeto.org/unix/hp-ux/lib/os/vpar/6.0/vpars-6.0-npiv-4AA3-8665ENW.pdf as a config example. Customers tend to follow examples.

00:60:B0 Integrity and HP9000 00:11:0a Compaq Proliant (500110a in servers) 00:01:FE EVA from DEC 00:17:A4 MSL Tape

Definition at line 36 of file HPVirtualServerDescription.java.

Constructor & Destructor Documentation

HPVirtualServerDescription ( String wwn )

inline

create an instance with brief set to false.

This is a convenience function to support the older constructor model

Exceptions

java.lang.NullPointerException if the given wwn is null

Parameters

wwn	the WWN to evaluate and describe

Definition at line 39 of file HPVirtualServerDescription.java.

Referenced by HPVirtualServerDescription.getDesc().

HPVirtualServerDescription	(	boolean	brief,
		String	wwn
	)

inline

create an instance with the given WWN.

Values given to the constructor are simply copied to internal variables for later use

Exceptions

java.lang.NullPointerException if the given wwn is null

Parameters

brief	whether an abbreviated description is requested
wwn	the WWN to evaluate and describe

Definition at line 74 of file HPVirtualServerDescription.java.

Member Function Documentation

String descPort ( )

inline

describe the WWPN's unique port label/index

Returns: the unique name for the port WWPN

Definition at line 107 of file HPVirtualServerDescription.java.

References WWNDesc.wwn.

static WWNDesc getDesc	(	boolean	strong,
		boolean	brief,
		String	wwn
	)

inlinestatic

If this class matches or describes the given WWN, returns a new instance of this class loaded with the given WWN.

Returns: new instance of this class, or null if the given wwn does not match this class

Parameters

strong	used to restrict matching to strong-matches only. This is a weak-confidence description, so will return null for strong-only matching
brief	is used to ask for a shorter description: a more concise nickname or alias
wwn	the WWN (WWPN or WWNN, but typically WWPN) to match

Definition at line 52 of file HPVirtualServerDescription.java.

References DevRole.max.

Referenced by WWNDescription.getWWNDescriptor().

static WWNDesc getDesc	(	boolean	strong,
		boolean	brief,
		String	wwn,
		int	role
	)

inlinestatic

If this class matches or describes the given WWN, returns a new instance of this class loaded with the given WWN.

Returns: new instance of this class, or null if the given wwn does not match this class

Parameters

strong	used to restrict matching to strong-matches only. This is a weak-confidence description, so will return null for strong-only matching
brief	is used to ask for a shorter description: a more concise nickname or alias
wwn	the WWN (WWPN or WWNN, but typically WWPN) to match
role	Role (Initiator/Switch/Target) to check for

Definition at line 60 of file HPVirtualServerDescription.java.

References HPVirtualServerDescription.HPVirtualServerDescription(), and WWNDesc.WWNDescInitiator.isA().

Here is the call graph for this function:

String toString ( )

inline

return a description or alias for this WWN; if brief is set to true during the call to getDesc(), then a shorter description or alias will be returned

See also: getDesc(boolean,boolean,String)

Returns: generated alias or nickname for the WWN

Definition at line 85 of file HPVirtualServerDescription.java.

References WWNDesc.wwn.

The documentation for this class was generated from the following file:

java/HPVirtualServerDescription.java
